Dr-120 Hydraulic Photovoltaic Spiral Pile Drilling Rig Crawler Type Drill Machine

FOB Reference Price:Get Latest Price
$90,000.00 - $130,000.00 / Sets | 1 Set/Sets (Min. Order)
Brand Name:
DINGLI
Model Number:
DR-120
Shipping:
Support Sea freight · Land freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 14 Negotiable
Customization:
Customized packaging (Min. Order: 1 Sets)
Graphic customization (Min. Order: 1 Sets)

More

Customized logo (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Applicable Industries:
Farms, Construction works , Energy & Mining
Place of Origin:
Shandong, China
After-sales Service Provided:
Engineers available to service machinery overseas
UNIQUE SELLING POINT:
Imported hydraulic system
Usage:
Pile Driver,Drill Hole Flling Pile Construction
Engine:
Cummins
Drilling Diameter:
500-1800mm
Power Source:
Diesel
Product Certification Verified
CE Certified.
Valid from 2018-02-01 until 2023-01-31
Supply Ability
Supply Ability:
30 Set/Sets per Month
Packaging & Delivery
Port
QINGDAO
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 14 To be negotiated
Video Description



Product Description

1 It is economical and efficient, mainly used in media and small-diameter pile civil construction;
2 Diesel engine has load induction and output power auto-control; the fuel consumption drops 5-10%;
3 5-level anti-vibration technology absorbs drilling vibrational frequency all-directionally to guarantee      high stability;
4 The special lubricating system makes sure that it can work under high-temperature environment;
5 The removable and symmetrical structure design doubles the service life of rotary drive key;a
6 Crowd cylinder has two operation modes-normal lifting and fast lifting to improve push efficiency;
7 Optional chassis incline alarm enhances construction safety;
8 Mast verticality auto-adjusting technology promises the pile accuracy.





Product TypeDR-120DR-150
Chassis length.(mm)42004800
Track width.(mm)600600
Machine weight.(t)3035
Maximum drilling depth.(m)3040
drilling diameter.(mm)500-1800500-1800
Engine brand

Yuchai/Weichai/Cummins

(Optional)

Weichai/Cummins

(Optional)

Engine rated power.(KW/rpm)151KW-176KW158KW-176KW
Maximum torque of power head.(KN.m)120150
Power head speed.(rpm)10-5010-50
Maximum working pressure of hydraulic system main pump.(MPa)3030
Maximum working pressure of hydraulic system auxiliary pump.(MPa)1212
Maximum bow rate of the main pump hydraulic systen.(L/min)112*2(Optional)112*2(Optional)
Maximum bow rate of the auxiliary pump hydraulic systen.(L/min)1616
Maximum pressure of the pressurization system.(KN)100100
Maximum lifting force of the pressurization system.(KN)8080
Maximum travel pressure system.(mm)30003000
Maximum lifting force of the main winch.(KN)150150
Maximum pull-up speed of the main winch. (m/min)5050
Maximum lifting force of the auxiliary winch.(KN)1515
Maximum pull-up speed of the auxiliary winch.(m/min)5050
Left and right inclination angle of drilling mast(°)±5±5
Forward and backward inclination angle of the drilling mast. (°)5/905/90
Maximum driving speed(KM/h)1.51.5
Maximum climbing angle.(°)2525
Maximum Driving torque.(KN.m)4500045000
Overall width of working state.(mm)42004200
Overall length of transport status.(mm)1300013000
Overall width of transport status.(mm)28002800
Overall height of transport status.(mm)35003550
Drill rod typeMachine LockMachine Lock
Drill rod whether to provide customYesYes
drill tools500-2000mm drilling bit,Drlling Barrel,Coring drill,Reaming drilling bit500-3000mm drilling bit,Drlling Barrel,Coring drill,Reaming drilling bit
Product Show



The company's latest research and development of the strong rotary drilling rigs are widely used in urban high-rise buildings, highways, railways, bridges, airports, ports and other basic pile construction, with a wide range of applications, high efficiency, stable performance, courteous service, environmental protection and energy conservation Advantage.

Extreme brand rotary drilling rig engine, hydraulic pump, cylinder, motor, power head, etc. are used at home and abroad brand-name products. Product safety and reliability, stable performance, handsome in appearance, the quality of domestic products have reached the advanced level of similar products








Our Advantage

1. Rotary Excavator is a kind of integrated Drilling Machine, which can be used in many kinds of bottom layer, having the characteristics of high speed of hole-forming, low pollution and strong maneuverability.

2. A short spiral drill can be used for dry digging, and a rotary drill can be used for wet digging. Equipped with punching hammer, the rotary excavator can be used to drill through the hard strata.

3. It can be expanded at the bottom of the hole, If the drilling tool is used. The rotary excavator adopts multi-layer telescopic drill pipe, which has less support time and low labor intensity.

4. Do not require mud circulating slag and cost saving, which is especially suitable for the construction of urban construction.

5. Hydraulic Oil models are selected according to local climate:  34#, 46# and 68#.

6. After the first time receiving of Rotary Drilling Rig, release diesel and clean the fuel tank. According to the climate, the diesel is added for the same model: -40#, -30#, -20#, -10# and 0#.

7. After 100 hours of all engines work, release and replace engine oil.

8. After 100 hours of all engines work, release and replace the coolant of the water tank.

9. Cummins engine, please timely contact the local service station for the record, so as to maintain it in future. Otherwise all consequences will be at your own peril, when out of warranty time.



 .

new condition water well hole uasge drilling rig

 When digging a hole, the drill bit revolves around the vertical axis and makes the axial movement. Soil under the torque and axial force of drill bit will  be cutting. During the process of working, under the action of centrifugal force and extrusion of the blade,  soil are destroyed and brroke up. The formation of soil flows pressure to the pit wall, at the same time along the surface up to ground. When the soil flow moves to the place, where is no barrier of pit wall, the whole excavation process is completed due to the centrifugal force of the broken earth being thrown around the pit.

Equipped with different drills:

Our Company
Our factory and working place

Refers to the sense of teamwork cooperation, team members’ performance is one of the characteristics for collaboration, the interdependence between team members, mutual respect, tolerance and respect for individual differences, a relationship of trust between each other, treat people sincerely, respect the promise, help each other and improve together; Share interests and achievements and share responsibility. The sense of cooperation should be cultivated in the process of working, and the person in charge of the team should first be the family in mind.

Shandong Dingli Construction Machinery Co., Ltd. is located in Tengzhou, the south of Shandong Province, where is the hometown of  Mo-tse. We specialize in the products of Crawler Rotary Drilling Rig, Wheeled Rotary Drilling Rig and Diesel Hammer, Photovoltaic Piling Machine and other Construction Machinery.  After our success in domestic market, we are ready to introduce our products to oversea market. With our rich experience and professional knowledge, we hope to bring our best service and products to oversea clients.

Our Certification:



new condition water well hole uasge drilling rig

Maintenance:

1. Check whether the oil quantity is sufficient, make sure the oil quality is normal.

2. Check whether the gear oil of each reducer is sufficient, make sure the oil quality is normal.

3. Check whether there is oil leakage phenomenon, tighten the loose hose.

4. Check whether the lifting device is flexible and whether the internal butter is contaminated.

5. Check whether there are cracks, rust, out of soldering and other damage in the frame structure, tighten bolts.

6. Check the electrical wire, sensor, operation button handle and other working conditions.

7. Check whether the main and auxiliary wire rope has broken, and its connection is safe and reliable, and whether the strength of pressure rope equipment is sufficient.

8. Whether all transmission parts are fastened.

9. The engine hydraulic system will preheat for 5-20 minutes in advance, according to different climate, and check whether the instrument is normal.

10. After 100 hours of the first time work, release the Hydraulic Oil, and oil of the radiator, clean and replace the damaged filter, use 3.5 litres of diesel. Inject 160 litres of special hydraulic oil, after clean the tank (Requirements: Oil level must not less than 80% of the level gauge of the fuel tank, when stop the machine.)



Our Customers



Our Services

Shandong Dingli Construction Machinery Co., Ltd. has more than 20 years of experience in mechanical production line, the company and scientific research, production, sales and after-sales as one of the large-scale comprehensive enterprise,we always adhere to the company's "Three For" spirit, "For community", "For customers" and "For responsibility". We provide you 24 hours of hotline for after-sales service, so that the majority of users can create greater value.

new condition water well hole uasge drilling rig

We have technical engineers, who are qualified to solve the problems that you suffered from our machines. As an experienced manufacturer, we have many sponsors in different areas from our country, we also have enough spare parts in our stock for clients immediately delivery.



FAQ



Q1: Are you a manufacturer?

A: Yes, our company was established in 1995. We are a professional Rotary Drilling Rig Manufacturer and have many years of technological exchange with Xozhou Heavy Industry Group.



Q2: What does your company produce?

A: The main products of our company include Ground Hole Drilling Machine, Crawler Rotary Drilling Rig, Wheeled Rotary Drilling Rig and Diesel Hammer, Photovoltaic Piling Machines and other Construction Machinery, etc.



Q3: How about your delivery time?

A: Normally the delivery time is about 7-15 days. For some special case, we can make it within 2 weeks, which depends on different products.



Q4: What methods of payment do you accept?

A: We accept T/T, L/C, D/P, D/A, etc. Of course we can have a discussion for this.
